Functioning principle | Drop in partial Oxygen pressure by reduction of the proportion of Oxygen in the air breathed in. |
Method of action | Addition of a determined quantity of Nitrogen to the air breathed in |
Simulated altitude | From 1200m. à 5500m. (more if requested) |
Partial O2 pressure: PO2 | From 138 up to 103 mmHg |
Percentage O2 range | From 18% up to 13,5% |
Percentage if HyperoxOne used | From 60% up to 13,5% |
Production of air mixed | Adapted following the consumption |
Maximum ventilatory flow | up to 190 l/mn |
Nitrogen supply | Minimum pressure 3 bars |
Electric power supply | 12 V. cc |
Power Consumption | 15 W. Maximum |
Control of PO2 | By Oxygene sensor |
Electronic control | By microprocessor |
Weight | 15 Kg ( without Nitrogen bottle) |
Dimensions | H.50 cm, L 40 cm, D 52 cm |
Respiratory tubing hose | Flexible, lengths from 60 cm up to 180 cm. |
Respiratory mask | In sterilisable silicone Double anti-return valves with a minimum dead volume |
